SMAJ14A Real Image SMAJ14A real image5572
Same model may have multiple batches, images only for reference.
SMAJ14A Real Image SMAJ14A real image5572
SMAJ14A Real Image SMAJ14A real image5572
Same model may have multiple batches, images only for reference.

SMAJ14A

Part No SMAJ14A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 14VWM 23.2VC SMA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Standard Package 1
Category Circuit Protection
Family TVS - Diodes
Series SMAJ
Packaging Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 14V
Voltage - Breakdown (Min) 15.6V
Voltage - Clamping (Max) @ Ipp 23.2V
Current - Peak Pulse (10/1000µs) 17.2A
Power - Peak Pulse 400W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AC SMA
Manufacturer Device Package DO-214AC (SMA)
Catalog SMAJ Series
Kits SMAJ-A-KIT - KIT TVS DIODE 400W UNI-DIR SMA
Win Source Part Number 046987-SMAJ14A
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SMAJ14A CAD Model

Description

The Littelfuse Inc. SMAJ14A is a Zener type TVS diode from the SMAJ series with a voltage rating of 14V reverse standoff and 15.6V breakdown minimum.

  • Maximum clamping voltage: 23.2V @ peak pulse current of 17.2A
  • Peak pulse power rating: 400W
  • Package: DO-214AC SMA
  • Operating temperature range: -55°C to 150°C
  • Applications: general purpose applications
  • Packaging: reel packaging
  • Channels: unidirectional and has one channel
