SMAJ16CA Real Image SMAJ16CA real image SMAJ16CA label picture
Same model may have multiple batches, images only for reference.
SMAJ16CA Real Image SMAJ16CA real image SMAJ16CA label picture
SMAJ16CA Real Image SMAJ16CA real image SMAJ16CA label picture
Same model may have multiple batches, images only for reference.

SMAJ16CA

Part No SMAJ16CA
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 16VWM 26VC SMA
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Standard Package 1
Category Circuit Protection
Family TVS - Diodes
Series SMAJ
Packaging Reel
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 16V
Voltage - Breakdown (Min) 17.8V
Voltage - Clamping (Max) @ Ipp 26V
Current - Peak Pulse (10/1000µs) 15.4A
Power - Peak Pulse 400W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AC SMA
Manufacturer Device Package DO-214AC (SMA)
Catalog SMAJ Series
Kits SMAJ-CA-KIT - KIT TVS DIODE 400W BI-DIR SMA
Win Source Part Number 042668-SMAJ16CA
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Industrial
Ultra Librarian 3D Model Ultra Librarian SMAJ16CA CAD Model

Description

The SMAJ16CA is a TVS diode from the SMAJ series of circuit protection products.

  • Type: unidirectional zener diode
  • Application: protection against voltage spikes and surges in electronic circuits
  • Voltage-reverse standoff: 16V
  • Breakdown voltage: 17.8V
  • Power peak pulse: 400W
  • Clamping voltage: 26V @ Ipp
  • Peak pulse current: 15.4A @ 10/1000µs
  • Operating temperature: -55°C ~ 150°C
  • Packaging: reel packaging
  • Standard package: 1
  • Compliance: RoHS compliant
  • Applications: computers and computer peripherals, communications and networking, consumer electronics, and industrial applications
