SMBJ30CA Real Image SMBJ30CA real image5594
Same model may have multiple batches, images only for reference.
SMBJ30CA Real Image SMBJ30CA real image5594
SMBJ30CA Real Image SMBJ30CA real image5594
Same model may have multiple batches, images only for reference.

SMBJ30CA

Part No SMBJ30CA
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS Diode Single Bi-Dir 30V 600W 2-Pin SMB T/R / TVS DIODE 30VWM 48.4VC SMB
Datasheet
SMBJ30CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection
Family TVS - Diodes
Manufacturer Littelfuse Inc.
Series SMBJ
Packaging Reel(TR)
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 30V
Voltage - Breakdown (Min) 33.3V
Voltage - Clamping (Max) @ Ipp 48.4V
Current - Peak Pulse (10/1000μs) 12.4A
Power - Peak Pulse 600W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AA, SMB
Manufacturer Device Package DO-214AA (SMBJ)
Win Source Part Number 029205-SMBJ30CA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Imaging, Video & Vision, Industrial
Family Name SMBJ30CA
Introduction Date October 07, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SMBJ30CA CAD Model

Description

The Littelfuse Inc. SMBJ30CA is a TVS-Diode manufactured by Littelfuse Inc.

  • Type: zener-type diode
  • Package: DO-214AA package
  • Channel: unidirectional
  • Voltage Rating: 30V
  • Breakdown Voltage: 33.3V
  • Clamping Voltage: 48.4V @ Ipp
  • Peak Pulse Current: 12.4A
  • Power Peak Pulse: 600W
  • Use: general purpose applications
  • ECCN: EAR99
  • Supply and Demand Status: sufficient
  • Applications: communications and networking, computers and computer peripherals, imaging, video and vision, and industrial applications
