SMCJ36A

Name: SMCJ36A
Brand: Littelfuse Inc.
SKU: 328512
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMCJ36A
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 36VWM 58.1VC SMC
Datasheet	SMCJ36A Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Littelfuse Inc.
Packaging	Reel - TR
Status	Active
Type	Zener
Unidirectional Channels	1
STAND-OFF Voltage (Vwm)	36V
Minimum Breakdown Voltage	40V
Max Clamping Voltage	58.1V
Peak Pulse Current(Ippm)	25.9A
Power Dissipation - Pd	1500W (1.5kW)
Applications	General Purpose
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	DO-214AB (SMCJ)
Win Source Part Number	029315-SMCJ36A
Popularity	Medium
Supply and Demand Status	Balance
Application Field	Used in Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Industrial
Package	Tape & Reel (TR);Cut Tape (CT)
Product Status	Active
Voltage - Reverse Standoff (Typ)	36V
Voltage - Breakdown (Min)	40V
Voltage - Clamping (Max) @ Ipp	58.1V
Current - Peak Pulse (10/1000µs)	25.8A
Power - Peak Pulse	1500W (1.5kW)
Power Line Protection	Yes
Operating Temperature	-55°C ~ 150°C
Grade	-
Mounting Type	Surface Mount
Package / Case	DO-214AB, SMC
Supplier Device Package	DO-214AB (SMCJ)
Package	Strip
Current - Peak Pulse (10/1000µs)	25.82A
Package / Case	DO-214AB (SMC)
Package	Tape & Reel (TR)
Ultra Librarian 3D Model	Ultra Librarian SMCJ36A CAD Model

Alternative Products

Description

The SMCJ36A is a Zener type electronic component manufactured by Littelfuse Inc.

Manufacturer: Littelfuse Inc.
Component Type: Zener
Package: DO-214AB (SMCJ)
Stand-off Voltage (Vwm): 36V
Minimum Breakdown Voltage: 40V
Maximum Clamping Voltage: 58.1V
Peak Pulse Current(Ippm): 25.9A
Power Dissipation - Pd: 1500W (1.5kW)
Applications: Computers and computer peripherals, communications and networking, consumer electronics, and industrial applications
