The SMCJ5.0A is a surface mount Transient Voltage Suppressor (TVS) diode manufactured by Littelfuse. It's designed to protect sensitive electronic components from damage caused by voltage transients, such as those induced by lightning, electrostatic discharge (ESD), and inductive load switching. This particular model is a unidirectional TVS diode.

Applications

• I/O Protection
• Analog Signal Line Protection
• Power Supply Protection
• Industrial Equipment
• Consumer Electronics
• Data Line Protection

Features

• Surface Mount: Easy to assemble with automated processes and saves PCB space.
• Unidirectional: Protects against positive voltage transients.
• 500μA at VR typical IR: Low leakage current to minimize power consumption.
• 3000W Peak Pulse Power: High surge capacity.
• Glass Passivated Chip Junction: High reliability.
• Fast Response Time: Clamps surge voltage quickly.
• Excellent Clamping Capability: Limits voltage across the protected components.
• RoHS Compliant: Environmentally friendly.

Benefits

• Protects sensitive electronic equipment from voltage transients.
• Increases system reliability.
• Reduces downtime due to equipment failure.
• Extends the life of electronic components.
• Provides a cost-effective solution for transient voltage protection.

Additional Details

The SMCJ5.0A has a standoff voltage of 5.0V. It’s designed to be used in circuits where the normal operating voltage does not exceed this value. When a transient voltage exceeding the breakdown voltage occurs, the TVS diode rapidly conducts and clamps the voltage to a safe level, preventing damage to downstream components. The device is packaged in an SMC (DO-214AB) package which is suitable for surface mounting on printed circuit boards. It can operate within a temperature range of -65°C to +150°C. Refer to the Littelfuse datasheet for detailed specifications on peak pulse current (Ipp) at varying pulse durations and other relevant electrical characteristics.
