Maxim Integrated DS1631S+T&R Digital Thermometer and Thermostat

The DS1631S+T&R is a high-precision digital thermometer and thermostat from Maxim Integrated that offers a versatile temperature sensing solution for a wide array of applications. This device provides both digital temperature readings and thermostat functionality, making it a dual-purpose component for temperature control systems.

Constructed with advanced silicon technology, the DS1631S+T&R features a temperature sensor with a digital output that can be easily interfaced with microcontrollers and other digital systems. The device operates over a temperature range of -55°C to +125°C, with an accuracy of ±0.5°C from -10°C to +85°C, ensuring precise temperature monitoring in critical applications.

One of the key features of the DS1631S+T&R is its programmable resolution, which can be set from 9 to 12 bits, allowing users to balance the trade-off between resolution and conversion time according to their specific requirements. With a 12-bit resolution, the device can detect temperature changes as small as 0.0625°C.

The DS1631S+T&R supports a 2-wire serial interface, compatible with I²C protocols, which enables easy integration into existing systems with minimal wiring. This serial interface also allows for multiple devices to be connected on the same bus, which is ideal for applications requiring several temperature sensing points.

Additionally, the device includes a thermostat function with user-programmable setpoints. The thermostat can trigger an alarm when the temperature exceeds the programmed limits, providing an automatic response to temperature changes without the need for constant monitoring by a microcontroller.

This product is available in a surface-mount SO package and is designed for tape and reel (T&R) packaging, which facilitates automated assembly processes, making it suitable for high-volume production. Whether used in environmental control systems, computer thermal management, or other temperature-sensitive applications, the DS1631S+T&R offers a reliable and efficient solution for digital temperature sensing and control.

Maxim Integrated's commitment to quality and performance is evident in the DS1631S+T&R, making it a top choice for designers and engineers looking for a dependable temperature monitoring component.
