Maxim Integrated DS4426T+ Low-Voltage Hex Level-Shifter

The Maxim Integrated DS4426T+ is a state-of-the-art low-voltage hex level-shifter designed for applications requiring the conversion of voltage levels in mixed-voltage systems. This compact, high-performance device is an ideal solution for interfacing devices or systems operating at different voltage levels within the range of 1.2V to 5.5V.

With its six open-drain outputs and two selectable input supply voltages, the DS4426T+ offers flexibility and ease of use for designers. The device allows for level shifting without the need for a direction pin, simplifying the design process and reducing the complexity of the circuit. Each output can be pulled up to a different voltage, depending on the requirements of the application, making it highly versatile for various interfacing scenarios.

The DS4426T+ features a maximum data rate of 200kbps, which is sufficient for low-speed signaling applications such as I²C or SMBus communication. The low on-resistance of the level shifter ensures minimal signal distortion and high integrity, which is crucial for maintaining the performance of the communication interface.

Designed with protection in mind, the DS4426T+ includes integrated overvoltage protection on the outputs, safeguarding connected devices from potential damage caused by voltage spikes. Additionally, the device is tolerant to high ESD events, ensuring robustness in harsh electrical environments.

The compact SOT23-8 package makes the DS4426T+ a space-saving choice for densely populated PCBs, where board real estate is at a premium. This small footprint, combined with the device's low power consumption, makes it an excellent choice for portable and battery-operated devices where efficiency is paramount.

Whether you are working on consumer electronics, mobile devices, or industrial control systems, the Maxim Integrated DS4426T+ offers a reliable and efficient solution for your level-shifting needs. By ensuring seamless communication between components with different voltage domains, this device helps to streamline the design process and enhance the overall performance of your electronic products.
