The MAX16054AZT is a highly versatile pushbutton on/off controller with debounce and ±15kV ESD protection, designed and manufactured by Maxim Integrated. This compact device is an ideal solution for adding a pushbutton on/off power switch to a variety of electronic applications, including portable devices, industrial equipment, and consumer electronics.

Key Features

• Debounce Circuitry: The MAX16054AZT integrates debounce circuitry that ensures clean, bounce-free switching, making it highly reliable for applications where precise control is necessary.
• Reverse Battery Protection: The device is designed to protect itself against incorrect battery installation, ensuring durability and longevity in consumer applications.
• Low Quiescent Current: With its low quiescent current, the MAX16054AZT is an energy-efficient choice, particularly suitable for battery-powered devices.
• High ESD Protection: The device offers ±15kV ESD protection, safeguarding against electrostatic discharges that can damage electronic components.
• Simple Interface: A straightforward interface allows for easy integration into system designs without the need for complex programming or additional components.

Applications

• Portable Devices
• Industrial Controls
• Consumer Electronics
• Computers and Peripherals

Technical Specifications

• Operating Voltage Range: 2.7V to 5.5V
• Operating Temperature Range: -40°C to +125°C
• Package Type: 6-Pin SOT23

The MAX16054AZT is available in a small, 6-pin SOT23 package, making it suitable for space-constrained applications. Its robust design and wide operating temperature range make it a reliable choice for both commercial and industrial environments. Whether you're designing a new product or upgrading an existing one, the MAX16054AZT from Maxim Integrated provides a simple yet effective solution for on/off control with pushbutton simplicity.
