Maxim Integrated MAX4736EGC+T Analog Multiplexer

The MAX4736EGC+T is a high-performance, low-voltage, single 8-channel multiplexer from Maxim Integrated, designed to provide precise analog signal management in a variety of applications. This device is part of Maxim's family of CMOS analog ICs, which are renowned for their reliability and efficiency.

This analog multiplexer operates with a single supply voltage ranging from +1.8V to +5.5V, making it ideal for battery-powered and portable devices where power conservation is crucial. The MAX4736EGC+T offers a low on-resistance of 4 ohms (max) that matches between channels to within 0.5 ohms (max) and remains flat over the specified analog signal range (0.5 ohms max). It also features a low leakage current of less than 0.1nA at +25°C, which helps to maintain signal integrity and reduce power consumption.

The MAX4736EGC+T comes in a compact 24-pin TQFN-EP package, which is suitable for space-constrained applications. The extended temperature range of -40°C to +85°C ensures reliable operation across various environmental conditions. Additionally, it features ESD protection greater than 2000V, according to the Human Body Model, providing robustness against static discharge.

With fast switching speeds and a transition time of less than 250ns, the MAX4736EGC+T is well-suited for sample-and-hold circuits, data acquisition systems, and communication systems. Its break-before-make switching action ensures that no two channels are connected simultaneously, preventing signal cross-talk and ensuring clean, glitch-free switching.

Integrating the MAX4736EGC+T into a design is straightforward, thanks to its digital control logic that is compatible with TTL and CMOS levels. This allows for easy interfacing with microcontrollers and digital logic systems. The multiplexer's single-ended configuration enables it to route one of eight inputs to a common output, simplifying signal routing and reducing the need for additional components.

Whether it's for audio and video signal routing, industrial control systems, or medical equipment, the Maxim Integrated MAX4736EGC+T analog multiplexer offers a mix of performance, compact size, and ease of use that makes it an excellent choice for designers looking to optimize their analog signal processing needs.
