MAX6325ESA+

Part No MAX6325ESA+
Manufacturer Maxim Integrated
Catalog PMIC - Voltage Reference
Description IC VREF SERIES 2.5V 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Reference Type Series, Buried Zener
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 2.5V
Output Current 15mA
Tolerance ±0.04%
Temperature Coefficient 1.5ppm/°C
Noise - 0.1Hz to 10Hz 1.5μVp-p
Noise - 10Hz to 10kHz 1.3μVrms
Voltage - Input 8 V to 36 V
Operating Supply Current 3mA
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 213235-MAX6325ESA+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX6325ESA+ CAD Model

Description

Maxim Integrated MAX6325ESA+ Precision Voltage Reference

The MAX6325ESA+ from Maxim Integrated is a high-precision, low-noise, low-drift voltage reference chip designed to ensure stability and accuracy in a wide range of applications. This device is an ideal choice for precision data converters, portable instrumentation, and industrial control systems where consistent voltage reference is critical for performance.

The MAX6325ESA+ series offers a fixed output voltage of 5V with an impressive initial accuracy of ±0.02%. The low temperature coefficient of 3ppm/°C (max) over the full automotive temperature range (-40°C to +125°C) ensures a reliable performance across various environmental conditions. The device also boasts an excellent long-term stability of 20ppm/1000 hours (max) at +25°C, making it suitable for applications requiring a stable voltage over time.

With a low supply current of 750µA (max) and the capability to source 15mA or sink 10mA of load current, the MAX6325ESA+ is both energy-efficient and versatile. Its low dropout voltage and wide supply range from 7V to 12.6V provide additional flexibility for system design.

The MAX6325ESA+ comes in an 8-pin SOIC package, which is compact and suitable for space-constrained applications. Moreover, the device features force and sense connections that allow for remote voltage sensing, compensating for any voltage drop due to the resistance of the PCB traces. This feature ensures that the exact voltage reference is delivered directly to the load, maintaining the high accuracy of the system.

For added reliability, the MAX6325ESA+ includes a thermal shutdown mechanism to protect the device from overheating, and it is specified for operation over the full automotive temperature range, making it robust for use in harsh environments.

Overall, the MAX6325ESA+ is a top-performing voltage reference that combines high precision, stability, and low power consumption, making it an excellent choice for designers looking to improve the accuracy and efficiency of their electronic systems.
