The MBR0560 is a Schottky Barrier Rectifier manufactured by Micro Commercial Components (MCC). It's designed for surface mount applications and offers a low forward voltage drop and high surge current capability, making it ideal for high-frequency rectification and protection applications.

Applications

• DC-DC converters
• Reverse polarity protection
• Freewheeling diodes in inductive circuits
• High-frequency rectification
• Solar power systems

Features

• Low forward voltage drop
• High surge current capability
• Surface mount package
• High-temperature soldering guaranteed
• Guard ring for transient protection
• RoHS compliant
• Lead-free finish

Benefits

• Increased efficiency in power conversion circuits due to the low forward voltage drop.
• Protection against voltage spikes with high surge current capability.
• Simplified assembly with surface mount packaging.
• Reliable performance in high-temperature environments.
• Environmentally friendly due to RoHS compliance and lead-free finish.
• Enhanced system reliability with guard ring protection.

Technical Specifications
