MCP1703T-3302E/CB

Name: MCP1703T-3302E/CB
Brand: Microchip Technology
SKU: 225720
Availability: InStock
Rating: 5 (284 reviews)

Part No	MCP1703T-3302E/CB
Manufacturer	Microchip Technology
Catalog	PMIC - Voltage Regulators - Linear
Description	LDO Regulator Pos 3.3V 0.25A 3-Pin SOT-23A T/R / IC REG LDO 3.3V 0.25A SOT23A-3
Datasheet	MCP1703T-3302E/CB Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $0.3850

Quantity

Unit Price

Ext. Price

95+

$0.5370

$51.015

230+

$0.4410

$101.430

355+

$0.4270

$151.585

485+

$0.4130

$200.305

625+

$0.4000

$250.000

840+

$0.3580

$300.720

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 218,550 pieces

MOQ: 95 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Categories	Integrated Circuits
Manufacturer	Microchip Technology
Packaging	Reel - TR
Status	Not For New Designs
Output Type	Fixed
Number of Regulators	1
Maximum Input Voltage	16V
Nominal Output Voltage (Min/Fixed)	3.3V
Dropout Voltage-Max	0.725V @ 250mA
Output Current	250mA
Operating Supply Current	5μA
PSRR	44dB (100Hz)
Control Protection Features	Over Current, Over Temperature, Short Circuit
Temperature Range - Operating	-40°C to 125°C
Regulator Topology	Positive Fixed
Output Voltage	3.3V
Voltage - Dropout (Typical)	0.525V @ 250mA
Mounting	SMD (SMT)
Case / Package	SOT-23A-3
Win Source Part Number	023068-MCP1703T-3302E/CB
Is this a common-used part?	Yes
Popularity	High
Fake Threat In the Open Market	32 pct.
Supply and Demand Status	Balance
Application Field	Used in Power Management, Portable Devices, Consumer Electronics
Family Name	MCP1703
Introduction Date	June 22, 2007
ECCN	EAR99
Country of Origin	China, Thailand, Taiwan
Halogen Free	Not Compliant
Estimated EOL Date	2026
Alternative Parts (Cross-Reference)	MCP1703AT-3302E/CB; AP2210N-3.3TRE1; LC1462CB3TR33; LC1462CB3TR331;

Description

Microchip Technology MCP1703T-3302E/CB Voltage Regulator

The MCP1703T-3302E/CB is a high-performance, low-dropout voltage regulator from Microchip Technology, designed to deliver a stable and reliable power supply for various electronic applications. This voltage regulator is particularly suitable for battery-powered devices, microcontrollers, and other digital systems that require low power consumption and a stable voltage output.

Key Features:

Output Voltage: The device provides a fixed output voltage of 3.3V, which is ideal for powering 3.3V logic devices and microcontrollers.
High Current Capability: It offers a high output current of up to 250 mA, accommodating a wide range of applications that require moderate power consumption.
Low Dropout Voltage: With a low dropout voltage of typically 178 mV at full load, the MCP1703T-3302E/CB ensures efficient operation even when the input voltage is close to the output voltage.
Low Quiescent Current: The regulator features a low quiescent current of 2 µA (typical), making it an excellent choice for battery-powered applications where power conservation is crucial.
Thermal Overload Protection: It includes built-in thermal overload protection that safeguards the device against damage due to excessive power dissipation and high operating temperatures.
Short-Circuit Protection: The MCP1703T-3302E/CB also offers short-circuit protection, enhancing the reliability and longevity of the device and the system it powers.

Package and Temperature Range:

The voltage regulator is available in a small SOT-223 package, which is suitable for space-constrained applications. It operates over an industrial temperature range of -40°C to +125°C, ensuring stable performance under varying environmental conditions.

Applications:

Due to its robust feature set, the MCP1703T-3302E/CB is ideal for a variety of applications, including:

Portable electronic devices
Wireless communication systems
Analog and digital sensor systems
Microcontroller power supplies
Smart battery circuits

With its combination of low power consumption, high current capability, and protection features, the MCP1703T-3302E/CB from Microchip Technology is a reliable choice for designers seeking a dependable voltage regulation solution.
