Microchip Technology MCP2200-I/SS USB to UART Serial Converter

The MCP2200-I/SS is a versatile USB to UART (Universal Asynchronous Receiver/Transmitter) serial converter from the trusted Microchip Technology. This compact integrated circuit (IC) is designed to provide a simple and efficient bridge between USB and serial communication ports, which is a crucial function in a wide range of consumer, industrial, and automotive applications.

The device operates at a voltage range of 3.0V to 5.5V, making it suitable for both 3.3V and 5V logic levels, and is available in a 20-pin SSOP (Shrink Small Outline Package) form factor, denoted by the suffix '/SS' in its name. Its built-in USB 2.0 Full-Speed transceiver and support for up to 12 Mbps USB data transfer rate ensures compatibility with a broad spectrum of USB hosts and peripherals.

Among its key features, the MCP2200-I/SS offers eight general-purpose input/output (GPIO) pins, which can be used for various custom functions, including status reporting and operational control. The device also includes configurable baud rate generation, EEPROM for storing custom configurations and descriptors, and support for hardware flow control using CTS/RTS lines.

Integrating the MCP2200-I/SS into your design is straightforward, thanks to Microchip's comprehensive support and resources, which include drivers, datasheets, and application notes. The device is also supported by the MCP2200 Configuration Utility, a user-friendly software tool that simplifies the process of configuring the converter's settings to match specific application requirements.

Whether you are developing USB connectivity for microcontroller-based systems, upgrading legacy peripherals to USB, or creating custom serial interface solutions, the MCP2200-I/SS offers a reliable and cost-effective solution backed by Microchip's reputation for quality and performance.
