Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Driven Configuration Low-Side
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 1.5A, 1.5A
Input Type Non-Inverting
Rise and Fall Time 20ns, 29ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-MSOP
Win Source Part Number 126751-MIC4427YMM-TR
Ultra Librarian 3D Model Ultra Librarian MIC4427YMM-TR CAD Model

Description

MIC4427YMM-TR Dual Non-Inverting MOSFET Driver from Microchip Technology

The MIC4427YMM-TR is a highly-reliable, dual non-inverting MOSFET driver designed by Microchip Technology, renowned for creating top-tier semiconductor products. This driver is specifically engineered to convert low power input signals into high current drives for MOSFETs, IGBTs, and other types of power transistors. Its robustness and efficiency make it an ideal choice for a multitude of applications, including motor controls, power supplies, and switching power converters.

Encased in an 8-pin MSOP (Mini Small Outline Package), the MIC4427YMM-TR provides a compact solution with a small footprint, suitable for space-constrained applications. The device operates with a supply voltage ranging from 4.5V to 18V, catering to a wide array of power requirements. This flexibility ensures that it can be integrated into diverse system designs with varying power levels.

One of the key features of the MIC4427YMM-TR is its high peak output current capability of up to 1.5A, which allows it to drive large capacitive loads with ease. This high current capability, combined with fast switching times, significantly enhances the performance of power circuits by reducing transition losses.

Furthermore, the driver boasts a low shoot-through current, minimizing the risk of potentially damaging cross-conduction in power transistors. This feature is critical for maintaining the integrity and longevity of the power devices being driven. Additionally, the MIC4427YMM-TR includes protection against under-voltage lockout, ensuring that the driver operates only when the supply voltage is within the specified range.

Designed with versatility in mind, the MIC4427YMM-TR is compatible with TTL and CMOS inputs, allowing for seamless integration with a variety of logic devices. Its latch-up immunity under any conditions within its power and voltage ratings offers extra reliability, which is essential for industrial and automotive environments where extreme conditions are often encountered.

In summary, the MIC4427YMM-TR from Microchip Technology is a powerful, reliable, and versatile dual non-inverting MOSFET driver that offers superior performance for driving power transistors in a wide range of applications.
