Products specifications

Category Integrated Circuits(ICs)
Family PMIC - Voltage Regulators - Linear TransistorDriver
Manufacturer Microchip Technology
Win Source Part Number 319948-MIC5158YM TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MIC5158YM TR CAD Model

Description

Microchip Technology's MIC5158YM TR: A Robust Voltage Regulator Solution

The MIC5158YM TR from Microchip Technology is a high-performance, adjustable output, super LDO™ voltage regulator that stands out for its exceptional features and reliability. Designed to cater to a wide range of applications, this regulator is an ideal choice for systems requiring a low dropout voltage and high output current, all within a small footprint. The MIC5158YM TR is suitable for various electronic devices, including personal computers, embedded systems, and telecommunications equipment.

One of the key attributes of the MIC5158YM TR is its ability to provide a high output current of up to 5A, making it capable of powering demanding circuits. It offers an adjustable output voltage range from 1.25V to 5.5V, which allows designers to tailor the output to meet specific requirements of the target application. The low dropout voltage ensures efficient operation even when the input voltage is close to the output voltage, thus conserving power and extending battery life in portable devices.

The MIC5158YM TR also boasts excellent load and line regulation, ensuring a stable output voltage despite variations in input voltage or load current. Its fast transient response is highly beneficial for applications where the load can vary abruptly, such as microprocessors and digital signal processors.

For safety and protection, the MIC5158YM TR features built-in overcurrent protection, which prevents damage to the regulator and the connected load in case of a fault condition. Additionally, thermal protection is included to shut down the regulator during excessive temperature conditions, further safeguarding the system.

Microchip Technology has packaged the MIC5158YM TR in a compact 5-pin power TO-263 package, which not only saves space on the PCB but also facilitates efficient heat dissipation. The device is also available in tape and reel format (TR suffix), which is ideal for automated manufacturing processes.

In summary, the MIC5158YM TR from Microchip Technology is a versatile and robust voltage regulator that offers designers the flexibility, protection, and performance needed for a wide array of power management applications.
