Product Overview: PIC24F16KL402T-I/ML

The PIC24F16KL402T-I/ML is a high-performance, low-power microcontroller designed by Microchip Technology, a leading provider of microcontroller and analog semiconductors. This microcontroller is a part of the PIC24F series, which is renowned for its efficient operation and versatility in various applications.

Key Features

• Core: The device features a 16-bit modified Harvard architecture with an up to 16 MIPS performance at 32 MHz. This provides a balanced trade-off between processing power and power consumption.
• Memory: It comes with 16 KB of Flash memory and 1 KB of RAM, suitable for handling complex code and data storage requirements.
• Timers: Multiple timers are available including 16-bit and 32-bit timers, which can be used for a wide range of timing and counting functions.
• Communication Interfaces: It includes versatile communication interfaces such as I²C, SPI, and UART for easy connectivity with peripherals and other microcontrollers.
• Analog Features: The device is equipped with a 10-bit Analog-to-Digital Converter (ADC) with up to 13 channels, allowing it to interface with analog sensors and devices.
• Operating Voltage: It operates within a range of 1.8V to 3.6V, making it ideal for battery-operated and portable applications.
• Temperature Range: The microcontroller is designed to operate within the industrial temperature range of -40°C to +85°C.
• Packaging: Available in a 28-pin QFN package, the PIC24F16KL402T-I/ML is compact and suitable for space-constrained applications.

Applications

The versatility of the PIC24F16KL402T-I/ML makes it an excellent choice for a broad spectrum of applications, including industrial control systems, automotive systems, consumer electronics, medical devices, and Internet of Things (IoT) applications. Its low-power consumption and robust feature set enable designers to create reliable and efficient systems.

Support and Resources

Microchip Technology provides extensive support for the PIC24F16KL402T-I/ML through its development tools, software libraries, and documentation. Designers can access the MPLAB® Integrated Development Environment (IDE) and a wide range of development boards and programmer/debugger tools to streamline the development process.
