Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube
Display Type LED
Configuration 7 Segment
Interface BCD
Digits or Characters A/D 3.5 Digits
Supply Current 1.8mA
Supply Voltage (V) 4.5V ~ 8V
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 28-LCC
Supplier Device Package 28-PLCC (11.51x11.51)
Family Part Number TC14433
Manufacturer Pack Quantity 39
MSL Level 1 (Unlimited)
Win Source Part Number 1264466-TC14433ELI
Manufacturer Homepage www.telcom-semi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TC14433ELI CAD Model

Description

Microchip Technology TC14433ELI Product Overview

The TC14433ELI is a high-quality, integrated analog-to-digital converter (ADC) from Microchip Technology, designed to provide precision and flexibility for a wide range of applications. This device combines a triple 3½ digit ADC with direct display drive of a Liquid Crystal Display (LCD), making it an ideal choice for battery-operated equipment due to its low power consumption and compact footprint.

The TC14433ELI offers a differential input and reference voltage, ensuring accurate readings in systems where signal integrity is paramount. It is capable of converting analog signals ranging from 0V to a reference voltage level, with a resolution of 0.05% of the full scale. The converter features an on-chip oscillator, which eliminates the need for external clocking devices, thus simplifying the design and reducing the overall bill of materials.

This device is particularly well-suited for portable instruments, digital panel meters, and other applications where power efficiency is crucial. The TC14433ELI operates within an extended temperature range, making it reliable in various environmental conditions. Its low power consumption allows for extended battery life in portable applications, which is a significant advantage for handheld devices.

The TC14433ELI also includes an auto-zero function to ensure offset errors are minimized, and a polarity indicator to automatically correct for negative inputs. The device boasts a high impedance differential input, which enhances noise rejection and improves measurement accuracy. Additionally, it includes an overrange and underrange signal output, which can be used to drive annunciators or provide interrupt signals to microprocessors.

With its robust feature set and high level of integration, the TC14433ELI from Microchip Technology offers engineers a reliable and efficient solution for precision analog-to-digital conversion. Its ability to drive an LCD directly, coupled with its low power consumption, makes it a versatile choice for designers aiming to create compact, energy-efficient electronic systems.
