Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Driven Configuration Low-Side
Channel Type Single
Number of Drivers 1
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4.5 V to 18 V
Logic Voltage - VIL, VIH 0.8V, 2.4V
Current - Peak Output (Source, Sink) 6A, 6A
Input Type Non-Inverting
Rise and Fall Time 25ns, 25ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 031933-TC4420EOA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TC4420
Introduction Date July 03, 1997
ECCN EAR99
Country of Origin China, Thailand
Halogen Free Not Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian TC4420EOA CAD Model

Description

Microchip Technology's TC4420EOA MOSFET Driver

The TC4420EOA is a robust, high-speed power MOSFET driver fabricated by Microchip Technology, designed to accommodate a wide range of power applications. This driver is capable of delivering a peak output current of 6A, making it an excellent choice for driving large capacitive loads with swift rise and fall times, typically around 25ns. Its single-output design is specifically engineered to convert TTL or CMOS input logic levels to a higher power output signal, thus enabling the control of power MOSFETs in a variety of applications.

Operating within a supply voltage range of 4.5V to 18V, the TC4420EOA is versatile and can be integrated into systems with varying power levels. This flexibility is particularly useful for designers looking to maintain signal fidelity across different platforms. The device is also equipped with latch-up protection, ensuring reliable operation even under the most demanding conditions. This feature is critical in safeguarding the device against overcurrent conditions that could potentially cause damage to the system.

The TC4420EOA is constructed with CMOS technology, which offers the dual benefits of low power consumption and reduced heat generation. This makes it an energy-efficient choice for continuous operation in power-sensitive designs. Additionally, the device boasts a wide operating temperature range of -40°C to +125°C, which ensures stable performance across various environmental conditions.

Enclosed in an 8-pin SOIC package, the TC4420EOA is compact and easy to incorporate into space-constrained designs. Its pin configuration is thoughtfully arranged to simplify PCB layout and to minimize the risk of cross-conduction due to stray capacitance. With its robust design and high-current driving capability, the TC4420EOA is an ideal solution for applications such as switching power supplies, motor controllers, and high-speed line drivers, where reliable and efficient power control is paramount.

For designers and engineers seeking a dependable MOSFET driver that combines high-speed operation with high current capability, the TC4420EOA from Microchip Technology is a compelling choice that promises to deliver performance and durability in a wide range of power management applications.
