The M25P16-VMN6TP TR is a 16-Mbit (2 MB) Serial Flash memory device, with advanced write protection mechanisms. Manufactured by Micron Technology (formerly Numonyx), it features a Serial Peripheral Interface (SPI) for high-performance communication.

Applications:

• Storage of embedded code for microcontrollers and microprocessors
• Data storage in consumer electronics such as set-top boxes, DVD players, and LCD TVs
• Firmware storage in networking equipment like routers and modems
• Storage of configuration data in industrial control systems
• Data logging in automotive systems

Features:

• 16-Mbit (2,097,152 x 8) memory array
• SPI interface with support for SPI modes 0 and 3
• High-performance: Up to 75 MHz clock rate
• Low power consumption: Deep Power-Down mode for reduced current draw
• Advanced write protection mechanisms: Software and hardware write protection
• Page program (256 bytes per page)
• Sector erase (4 KB) and Block erase (64 KB) capabilities
• Single 2.7V to 3.6V power supply

Benefits:

• Reliable storage for critical code and data
• Fast data access and transfer rates through the SPI interface
• Extended battery life in portable applications due to low power consumption
• Prevention of accidental data corruption with write protection features
• Flexible memory management with page program, sector erase, and block erase options
• Simplified system design with single power supply requirement

Technical Specifications:

The M25P16-VMN6TP TR operates within a supply voltage range of 2.7V to 3.6V. It supports SPI clock frequencies up to 75 MHz. The device offers a page program size of 256 bytes, a sector erase size of 4 KB, and a block erase size of 64 KB. The operating temperature range is -40°C to +85°C. The package type is SOIC-8. It features electronic signature and parameter pages for identification and configuration. This device uses CMOS technology. It has an endurance of 100,000 program/erase cycles per sector, and data retention is guaranteed for 20 years. The SOIC package is lead-free and RoHS compliant.

The M25P16-VMN6TP TR provides a reliable and efficient solution for serial flash memory applications. Its high performance, low power consumption, and advanced write protection features make it suitable for a wide range of embedded systems.
