VCT9678H-EM-A3

Part No VCT9678H-EM-A3
Manufacturer Micronas GmbH
Catalog HOT - SALES and EOL Components (U - Z)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Micronas GmbH
Win Source Part Number 397700-VCT9678H-EM-A3
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian VCT9678H-EM-A3 CAD Model

Description

The Micronas VCT9678H-EM-A3 is a single-chip CMOS multi-standard TV processor designed for a wide range of analog television applications. This highly integrated IC combines video, audio, and control functionalities, making it suitable for cost-effective TV designs.

Applications:

  • Analog televisions (CRT, LCD, Plasma)
  • Video recorders (VCRs)
  • Set-top boxes
  • Automotive entertainment systems
  • Surveillance systems

Features:

  • Multi-standard video decoder: Supports PAL, SECAM, and NTSC standards.
  • Integrated audio processor: Includes audio decoding and processing capabilities.
  • On-screen display (OSD) controller: Allows for displaying text and graphics on the screen.
  • Microcontroller interface: Enables communication with external microcontrollers for system control.
  • Built-in comb filter: Improves video quality by separating luminance and chrominance signals.
  • Teletext decoder: Supports teletext functionality for accessing text-based information services.
  • Automatic gain control (AGC): Maintains stable signal levels for video and audio.
  • Deflection processing for CRT displays.

Benefits:

  • Reduced component count: Integration of multiple functions into a single chip simplifies the design and reduces the number of external components required.
  • Cost-effective solution: The highly integrated design lowers the overall system cost.
  • Improved video quality: The built-in comb filter and other video processing features enhance the picture quality.
  • Enhanced audio performance: The integrated audio processor provides high-quality audio decoding and processing.
  • Flexible system control: The microcontroller interface allows for flexible system control and customization.
  • Compact design: Smaller PCB footprint due to high integration

Additional Details:

The VCT9678H-EM-A3 typically operates from a 3.3V power supply. It's packaged in a TQFP (Thin Quad Flat Pack) package. Detailed technical specifications, including pinout diagrams, timing diagrams, and electrical characteristics, are available in the product datasheet. This IC is designed for experienced electronics engineers and requires knowledge of analog television standards and circuit design principles for proper implementation.The device also provides versatile interfaces for external memory and peripherals, enabling flexible system design. It features power-saving modes to minimize energy consumption in standby or low-activity states.
