Products specifications

Category RF and Wireless - RF Power Dividers/Splitters
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Insertion Loss 0.9dB
Frequency 500 MHz ~ 2.5 GHz
Specifications Isolation (Min) 9dB, 1.3 VSWR (Max), 5° Imbalance (Max)
Size / Dimension 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Package / Case 12-VQFN Exposed Pad
Standard Package 2,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 137671-GP2S1+
Ultra Librarian 3D Model Ultra Librarian GP2S1+ CAD Model

Description

The 137671-GP2S1+ is an RF power divider/splitter designed for use in various applications. It has a frequency range of 500 MHz to 2.5 GHz, allowing for signal division or splitting within this range. With an insertion loss of 0.9dB, this power divider/splitter provides efficient signal division while minimizing signal loss. The module comes in a 12-VQFN exposed pad package, making it easy to integrate into your circuit design. With a standard package of 2,000 pcs, this power divider/splitter is readily available for your electronic projects. Manufactured by Mini-Circuits, a trusted name in the industry, this module is of high quality and is currently active in the market.
