172298-1216 Real Image
Same model may have multiple batches, images only for reference.

172298-1216

Part No 172298-1216
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Ultra-Fit Vertical Header, 3.50mm Pitch, Dual Row, 16 Circuits, with Kinked Pins, 0.38µm Gold (Au) Plating, Black,...
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Gold
Contact Plating Gold
Country of Origin US
Current Rating 11 A
Fastening Type Latch
Height 14.25 mm
Maximum Operating Temperature 120 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 16
Number of Contacts 16
Number of Positions 16
Number of Rows 2
Orientation Vertical
Pitch 3.5052 mm
Plating Tin
RoHS Compliant
Row Spacing 4.5974 mm
Termination Kinked Pin
Voltage Rating 400 V
Win Source Part Number 1004956-172298-1216
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 172298-1216 CAD Model

Description

The 1004956-172298-1216 is a male pin connector manufactured by Molex, LLC.

  • Contacts: 16
  • Orientation: vertical
  • Pitch: 3.5052 mm
  • Row Spacing: 4.5974 mm
  • Voltage Rating: 400V
  • Current Rating: 11A
  • Contact Material: gold
  • Contact Plating: gold
  • Termination: kinked pins
  • Fastening Type: latch
  • Maximum Operating Temperature: 120 °C
  • Temperature Range: -40 °C to 120 °C
  • RoHS Compliant: yes
