Same model may have multiple batches, images only for reference.
26-48-1145 Real Image
Same model may have multiple batches, images only for reference.

26-48-1145

Part No 26-48-1145
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Wire to Board HDR 14 POS 3.96mm Solder ST Thru-Hole Package
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Brass
Contact Plating Tin
Contact Resistance 10 mΩ
Country of Origin US
Current Rating 7 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Housing Material Polyester
Lead Pitch 3.96 mm
Maximum Operating Temperature 75 °C
Min Operating Temperature 0 °C
Mount Through Hole
Number of Circuits 14
Number of Contacts 14
Number of Positions 14
Number of Rows 1
Orientation Right Angle, Vertical
Packaging Bulk
Pitch 3.96 mm
Radiation Hardening No
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 1038819-26-48-1145
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 26-48-1145 CAD Model

Description

The Molex 1038819-26-48-1145 is a circular connector housing with 14 positions and a pitch of 3.96 mm.

  • Manufacturer: Molex
  • Positions: 14
  • Pitch: 3.96 mm
  • Rows: Single
  • Termination: Soldering
  • Contact Material: Brass
  • Voltage Rating: Up to 250 V
  • Current Rating: 7 A
  • Gender: Male
  • Material: Polyester
  • Orientation: Right-angle and Vertical
  • Plating: Tin
  • Contact Resistance: 10 mΩ
  • Category: Circular connectors - housings
  • RoHS: Compliant
  • Max Operating Temperature: 75°C
  • Mounting: Through hole
  • Supply and Demand Status: Shortage
