The Molex 500024-2481 is a Pico-Clasp Wire-to-Board Connector. This connector is designed for tight-packaging applications, providing a secure and reliable connection between a wire harness and a printed circuit board (PCB). Its small size and positive locking mechanism make it ideal for applications where space is limited and vibration resistance is essential.

Applications:

• Consumer electronics
• Mobile devices
• Medical devices
• Industrial control equipment
• Automotive electronics
• Robotics
• Gaming consoles
• Lighting systems
• Security systems
• HVAC systems

Features:

• Pico-Clasp design for secure mating
• 24 circuits/positions
• Single Row
• 1.00mm pitch
• Surface mount termination
• Positive locking mechanism
• Compact size
• RoHS Compliant

Benefits:

• Ensured reliable electrical connection due to secure latching
• Space saving in compact devices due to small footprint
• Reduced risk of accidental disconnection due to positive lock
• Suitable for reflow soldering processes
• Durable performance over a wide temperature range
• Simplified manufacturing process through automated assembly compatibility

Additional Details:

The 500024-2481 is a surface mount connector with a 1.00mm pitch. The connector utilizes a positive locking feature, ensuring a secure connection even in high-vibration environments. The housing material is typically a UL 94V-0 rated plastic, providing flammability resistance. The terminals are typically tin or gold plated for improved conductivity and corrosion resistance. This connector is often used in applications where a compact, reliable, and vibration-resistant wire-to-board connection is needed. The operating temperature range is typically -40°C to +85°C. The mating connector is typically a crimp terminal attached to a wire, which then mates with the header on the PCB.
