501953-0307 Real Image
Same model may have multiple batches, images only for reference.

501953-0307

Part No 501953-0307
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 3 POS 1mm Solder RA Side Entry SMD Pico-Clasp™ T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Gender Male
Contact Material Brass, Bronze
Contact Plating Tin
Country of Origin JP
Current Rating 400 mA
Depth 5.35 mm
Fastening Type Ramp
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Natural
Housing Material Nylon
Length 5 mm
Maximum Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 3
Number of Contacts 3
Number of Positions 3
Number of Rows 1
Orientation Right Angle, Vertical
Pitch 1 mm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 50 V
Win Source Part Number 995566-501953-0307
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 501953-0307 CAD Model

Description

This Molex, LLC male pin connector is a 3-position, right angle/vertical connector with a pitch of 1 mm.

  • Positions: 3
  • Orientation: Right Angle/Vertical
  • Pitch: 1 mm
  • Color: Natural
  • Termination: Solder
  • Contact Material: Brass and Bronze
  • Contact Plating: Tin
  • Voltage Rating: 50 V
  • Current Rating: 400 mA
  • Length: 5 mm
  • Depth: 5.35 mm
  • Insulation Resistance: 100 MΩ
  • RoHS Compliant: Yes
  • Suitable for Use In: Circular connector housings
