The Molex 503480-1000 is a Micro-Latch Wire-to-Board Connector Housing. This connector system provides a secure and reliable connection for various electronic applications where space is limited. It's designed for ease of use and offers a positive locking mechanism to prevent accidental disconnections.

Applications:

• Consumer Electronics
• Industrial Equipment
• Medical Devices
• Automotive Applications
• Data Communications Equipment

Features:

• Micro-Latch Design
• Wire-to-Board Configuration
• Single Row
• 10 Circuits
• Positive Locking Mechanism
• Durable Construction

Benefits:

• Secure Connection: The positive locking mechanism ensures a reliable connection, preventing accidental disconnections due to vibration or other environmental factors.
• Compact Size: The micro-latch design allows for high-density packaging, making it ideal for applications where space is limited.
• Easy to Use: The connector is designed for easy mating and unmating, simplifying assembly and maintenance.
• Versatile Application: Suitable for a wide range of wire-to-board applications, providing a flexible solution for various electronic designs.
• Robust Design: Durable materials and construction ensure reliable performance in harsh environments.

Additional Details:

The 503480-1000 connector housing is typically used with crimp terminals designed for the Micro-Latch system. Wire gauges can vary, but typically range from 26-30 AWG. The housing is made from a durable thermoplastic material. The operating temperature range is typically -40°C to +105°C. Mate with the appropriate Molex header for a complete wire-to-board connection. Consult the Molex datasheet for specific voltage and current ratings, mating information, and applicable wire sizes.

The Micro-Latch system's small size and secure locking feature make it a popular choice in many electronic applications where a reliable and compact wire-to-board connection is required.
