Same model may have multiple batches, images only for reference.
53258-0229 Real Image
Same model may have multiple batches, images only for reference.

53258-0229

Part No 53258-0229
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Power PIN 2 POS Solder RA Thru-Hole 4 Terminal 1 Port Reel
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Gender Male
Contact Material Brass
Contact Plating Tin
Contact Resistance 10 mΩ
Country of Origin KR
Current Rating 2 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Material Polyester
Maximum Operating Temperature 105 °C
Max Voltage Rating (AC) 250 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 2
Number of Contacts 2
Number of Positions 2
Number of Rows 1
Orientation Vertical, Right Angle
Pitch 3.5 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Win Source Part Number 961584-53258-0229
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53258-0229 CAD Model

Description

The Molex 961584-53258-0229 is a polyester housing circular connector with two positions and a pitch of 3.5mm.

  • Positions: 2
  • Pitch: 3.5mm
  • Termination: Through-hole
  • Voltage Rating: 250V
  • Current Rating: 2A
  • Contact Material: Brass
  • Contact Resistance: 10 mΩ
  • Gender: Male
  • Contact Plating: Tin
  • Orientation: Vertical or right angle
