MP2307DN-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP2307DN-LF-Z real image3580
Same model may have multiple batches, images only for reference.
MP2307DN-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP2307DN-LF-Z real image3580
MP2307DN-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP2307DN-LF-Z real image3580
Same model may have multiple batches, images only for reference.

MP2307DN-LF-Z

Part No MP2307DN-LF-Z
Manufacturer Monolithic Power Systems Inc.
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 3A 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Package Tape & Reel (TR);Cut Tape (CT);
Product Status Not For New Designs
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Voltage - Input (Min) 4.75V
Voltage - Input (Max) 23V
Voltage - Output (Min/Fixed) 0.925V
Voltage - Output (Max) 20V
Current - Output 3A
Frequency - Switching 340kHz
Synchronous Rectifier Yes
Operating Temperature -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width) Exposed Pad
Supplier Device Package 8-SOIC-EP
Ultra Librarian 3D Model Ultra Librarian MP2307DN-LF-Z CAD Model

Description

The Monolithic Power Systems Inc. electronic component is a step-down type.

  • Packaging: reel - TR
  • Mounting: SMD (SMT)
  • Output Type: adjustable
  • Topology: buck
  • Frequency of Switching: 340kHz
  • Number of Outputs: 1
  • Synchronous Rectifier: Yes
  • Output Current: 3A
  • Family Name: MP2307
  • Operating Temperature Range: -40°C to 85°C (TA)
  • Case / Package: 8-SOIC-EP
  • Purpose: step-down
  • Maximum Input Voltage: 23V
  • Nominal Output Voltage (min/fixed): 0.925V
  • Maximum Output Voltage: 20V
  • Minimum Input Voltage: 4.75V
  • Alternative Parts (cross-reference): TS3552CS RLG, LT1374IS8#TR, and LT1374CS8#TR
  • Introduction Date: March 14, 2006
  • ECCN: EAR99
  • Country of Origin: China
  • Estimated EOL Date: 2022
  • Supply and Demand Status: sufficient
