77203HVC Real Image
Same model may have multiple batches, images only for reference.

77203HVC

Part No 77203HVC
Manufacturer Murata Power Solutions Inc.
Catalog Pulse Transformers
Description PULSE XFMR 2:1:1 1MH / 1mH SCR and Triac Trigger (Encapsulated) Pulse Transformer 2:1:1 Through Hole
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Pulse Transformers
Mfr Murata Power Solutions Inc.
Package Tube
Transformer Type SCR and Triac Trigger (Encapsulated)
Inductance 1mH
ET (Volt-Time) 120VµS
Mounting Type Through Hole
Dimension 1.000" L x 0.799" W (25.40mm x 20.30mm)
Height - Seated (Max) 0.484" (12.30mm)
Temperature Range - Operating 0°C ~ 70°C
Base Product Number 772
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.2000
Other Names 77203HVC-ND,811-3699
Standard Package 25
Win Source Part Number 1024313-77203HVC
Ultra Librarian 3D Model Ultra Librarian 77203HVC CAD Model

Description

The 1024313-77203HVC is a pulse transformer that is designed for use in various applications.

  • Mounting Type: Through-Hole
  • Transformer Type: SCR and Triac Trigger (Encapsulated)
  • Standard Package: 25
  • Height: 0.484" (12.30mm)
  • Operating Temperature Range: 0°C to 70°C
  • ET (Volt-Time): 120VµS
