LP39542TLX/NOPB National Semiconductor (TI) – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

LP39542TLX/NOPB

Part No LP39542TLX/NOPB
Manufacturer National Semiconductor (TI)
Catalog PMIC - LED Drivers
Description IC LED DRV RGLTR PWM 36USMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type DC DC Regulator
Topology Step-Up (Boost)
Internal Switch(s) Yes
Number of Outputs 13
Voltage - Supply (Min) 3V
Voltage - Supply (Max) 5.5V
Voltage - Output 4V ~ 5.3V
Current - Output / Channel 900mA (Switch)
Frequency 2MHz
Dimming PWM
Applications Backlight, Camera Flash
Temperature Range - Operating -30°C ~ 85°C (TA)
Mounting Type Surface Mount
Case / Package 36-WFBGA
Supplier Device Package 36-uSMD
Package Bulk
Supply and Demand Status Normal
Win Source Part Number 1497127-LP39542TLX/NOPB
Ultra Librarian 3D Model Ultra Librarian LP39542TLX/NOPB CAD Model
