74LVC08AD,118 Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

74LVC08AD,118

Part No 74LVC08AD,118
Manufacturer Nexperia USA Inc.
Catalog Logic - Gates and Inverters
Description Logic Gates Quad 2-input AND gate
Datasheet
74LVC08AD,118 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Logic - Gates and Inverters
Mfr Nexperia USA Inc.
Series 74LVC
Package Tape & Reel
Product Status Active
Logic Type AND Gate
Number of Circuits 4
Number of Inputs 2
Voltage - Supply 1.2V ~ 3.6V
Current - Quiescent (Max) 40 µA
Current - Output High, Low 24mA, 24mA
Input Logic Level - Low 0.12V ~ 0.8V
Input Logic Level - High 1.08V ~ 2V
Max Propagation Delay @ V, Max CL 4.1ns @ 3.3V, 50pF
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Supplier Device Package 14-SO
Package / Case 14-SOIC (0.154", 3.90mm Width)
Base Product Number 74LVC08
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 815941-74LVC08AD,118
Ultra Librarian 3D Model Ultra Librarian 74LVC08AD,118 CAD Model

Description

The 815941-74LVC08AD,118 is an AND gate integrated circuit from the 74LVC series. It is designed for logic applications and is available in a 14-SOIC package. This device is manufactured by Nexperia USA Inc..

  • Voltage Supply Range: 1.2V to 3.6V
  • Temperature Range: -40°C to 125°C
  • Maximum Propagation Delay: 4.1ns @ 3.3V
  • Maximum Quiescent Current: 40µA
  • Inputs: Two
  • Current Output: 24mA (high and low states)
  • Product Status: Active
  • Package Quantity: 2,500 pieces
