HEF4052BT,653 Nexperia USA Inc. HEF4052BT,653 real image 3 HEF4052BT,653 label picture 2 HEF4052BT,653 label picture 2 HEF4052BT,653 real image
Same model may have multiple batches, images only for reference.
HEF4052BT,653 Nexperia USA Inc. HEF4052BT,653 real image 3 HEF4052BT,653 label picture 2 HEF4052BT,653 label picture 2 HEF4052BT,653 real image
HEF4052BT,653 Nexperia USA Inc. HEF4052BT,653 real image 3 HEF4052BT,653 label picture 2 HEF4052BT,653 label picture 2 HEF4052BT,653 real image
Same model may have multiple batches, images only for reference.

HEF4052BT,653

Part No HEF4052BT,653
Manufacturer Nexperia USA Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC MUX/DEMUX DUAL 4X1 16SOIC
Datasheet
HEF4052BT,653 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Switch Circuit SP4T
Number of Circuits 2
Max On Resistance 155 Ohm
Channel-to-Channel Matching (ΔRon) 5 Ohm
Single Supply Voltage (V+) 3 V to 15 V
-3db Bandwidth 70MHz
Channel Capacitance(CS off, CD off) 7.5pF
Max Leakage Current (IS off) 200nA
Crosstalk -50dB @ 1MHz
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 16-SO
Win Source Part Number 1043116-HEF4052BT,653
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian HEF4052BT,653 CAD Model

Description

The Nexperia USA Inc. 1043116-HEF4052BT,653 is an integrated circuit component with sufficient supply and is currently active in the market.

  • Manufacturer: Nexperia USA Inc.
  • Category: Integrated Circuit
  • Operating Temperature: -40°C to 125°C (TA)
  • Case/Package: 16-SO
  • Max On-Resistance: 155 Ohm
  • Single Supply Voltage: 3V to 15V
