PBSS4160DPN,115 Nexperia USA Inc. PBSS4160DPN,115 real image PBSS4160DPN,115 label picture
Same model may have multiple batches, images only for reference.
PBSS4160DPN,115 Nexperia USA Inc. PBSS4160DPN,115 real image PBSS4160DPN,115 label picture
PBSS4160DPN,115 Nexperia USA Inc. PBSS4160DPN,115 real image PBSS4160DPN,115 label picture
Same model may have multiple batches, images only for reference.

PBSS4160DPN,115

Part No PBSS4160DPN,115
Manufacturer Nexperia USA Inc.
Catalog Transistors (BJT) - Arrays
Description TRANS NPN/PNP 60V 6TSOP
Datasheet
PBSS4160DPN,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Transistor Polarity NPN, PNP
Maximum Current Collector 870mA, 770mA
VCEO Maximum Collector-Emitter Breakdown Voltage 60V
Max Vce (sat) 250mV @ 100mA, 1A / 330mV @ 100mA, 1A
Collector Cut-off Current(Max) 100nA
Typical Gain (hFE) (Min) 200 @ 500mA, 5V / 150 @ 500mA, 5V
Maximum Power Dissipation 420mW
Frequency - Transition 220MHz, 185MHz
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package 6-TSOP
Win Source Part Number 1086469-PBSS4160DPN,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PBSS4160DPN,115 CAD Model

Description

The PBSS4160DPN,115 is a Nexperia USA Inc. manufactured transistor that is ideal for use in a wide range of applications.

  • Package: 6-TSOP
  • Suitable for: Discrete semiconductor products
  • Maximum Collector-Emitter Breakdown Voltage: 60V
  • Maximum Power Dissipation: 420mW
  • Frequency Transition: 220MHz, 185MHz
  • Transistor Polarity: NPN, PNP
  • Maximum Current Collector: 870mA, 770mA
  • Maximum Collector Cut-off Current: 100nA
  • Typical Gain (hFE) (Min): 200 @ 500mA, 5V / 150 @ 500mA, 5V
  • Maximum Vce (sat): 250mV @ 100mA, 1A / 330mV @ 100mA, 1A
  • Status: Active
  • Popularity: Medium
  • Supply and Demand Status: Sufficient
