PSMN4R0-30YL,115 Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

PSMN4R0-30YL,115

Part No PSMN4R0-30YL,115
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 30V 100A LFPAK / Trans MOSFET N-CH 30V 100A 5-Pin(4+Tab) LFPAK T/R
Datasheet
PSMN4R0-30YL,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 30V
Current - Continuous Drain (Id) @ 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Vgs(th) (Maximum) @ Id 2.15V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs 36.6nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 2090pF @ 12V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 69W (Tc)
Rds On (Maximum) @ Id, Vgs 4 mOhm @ 15A, 10V
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting SMD
Manufacturer Package LFPAK56, Power-SO8
Package SC-100, SOT-669
Win Source Part Number 792628-PSMN4R0-30YL,115
Popularity Medium
Supply and Demand Status Limited
Family Name PSMN4R0-30YL
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian PSMN4R0-30YL,115 CAD Model

Description

The Nexperia USA Inc. PSMN4R0-30YL MOSFET is a reliable and efficient way to regulate voltage in electronic circuits.

  • Maximum Power: 69W
  • Maximum Current: 100A (Tc)
  • Drain Source Voltage: 30V
  • Gate-Source Voltage: ±20V
  • Package / Case: LFPAK56, Power-SO8
  • Mounting Type: SMD
  • Suitable For: Discrete Semiconductor Products
  • Halogen Free: Yes
  • Country of Origin: Philippines
  • Estimated EOL Date: 2029
