PSMN4R2-30MLDX

Name: PSMN4R2-30MLDX
Brand: Nexperia USA Inc.
SKU: 792630
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PSMN4R2-30MLDX
Manufacturer	Nexperia USA Inc.
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 70A LFPAK33 / Trans MOSFET N-CH 30V 70A 8-Pin LFPAK EP T/R
Datasheet	PSMN4R2-30MLDX Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Nexperia USA Inc.
Packaging	Reel package
Channel Type Type	N
Technology	MOSFET
Drain Source Voltage	30V
Current - Continuous Drain (Id) @ 25°C	70A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Vgs(th) (Maximum) @ Id	2.2V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs	29.3nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	1795pF 15V
Vgs (Maximum)	±20V
FET Feature	Schottky Diode (Body)
Power Dissipation (Maximum)	65W (Tc)
Rds On (Maximum) @ Id, Vgs	4.3 mOhm @ 25A, 10V
Operating Temperature Range	-55°C ~ 175°C (TJ)
Mounting	SMD
Manufacturer Package	LFPAK33
Package	SOT-1210, 8-LFPAK33 (5-Lead)
Win Source Part Number	792630-PSMN4R2-30MLDX
Popularity	Medium
Supply and Demand Status	Limited
Family Name	PSMN4R2-30MLD
Introduction Date	August 22, 2013
ECCN	EAR99
Country of Origin	Philippines
Halogen Free	Compliant
Estimated EOL Date	2029
Ultra Librarian 3D Model	Ultra Librarian PSMN4R2-30MLDX CAD Model

Alternative Products

Description

The Nexperia USA Inc. PSMN4R2-30MLDX MOSFET is a reliable and efficient way to regulate voltage in electronic circuits.

Maximum Power: 65W
Maximum Current: 70A (Tc)
Drain Source Voltage: 30V
Gate-Source Voltage: ±20V
Package / Case: SOT-1210, 8-LFPAK33 (5-Lead)
Mounting Type: SMD
Suitable For: Discrete Semiconductor Products
Halogen Free: Yes
Country of Origin: China
Estimated EOL Date: 2029
