Same model may have multiple batches, images only for reference.
FR01FR10H-06XL NKK Switches – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

FR01FR10H-06XL

Part No FR01FR10H-06XL
Manufacturer NKK Switches
Catalog DIP Switches
Description SWITCH ROTARY DIP BCD 0.1A 5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Circuit BCD
Number of Positions 10
Current Rating (Amps) 100mA
Voltage Rating 5VDC
Actuator Type Rotary for Tool
Actuator Level Flush, Recessed
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.394" (10.00mm)
Mounting Type Through Hole, Right Angle
Termination Style PC Pin
Pitch 0.100" (2.54mm), Full
Washable No
Temperature Range - Operating -25°C ~ 85°C
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1552422-FR01FR10H-06XL
Ultra Librarian 3D Model Ultra Librarian FR01FR10H-06XL CAD Model
