NRF24LE1-F16Q48-R Real Image NRF24LE1-F16Q48-R label picture
NRF24LE1-F16Q48-R Real Image NRF24LE1-F16Q48-R label picture
Same model may have multiple batches, images only for reference.

NRF24LE1-F16Q48-R

Part No NRF24LE1-F16Q48-R
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU ISM>1GHZ 48-VFQFN
Datasheet
NRF24LE1-F16Q48-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Nordic Semiconductor ASA
Packaging Reel - TR
Status Active
Type TxRx + MCU
RF Family/Standard General ISM > 1GHZ
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 2Mbps
Power - Output 0dBm
Sensitivity -94dBm
Memory Size 16kB Flash, 1kB SRAM
Serial Interfaces I2C, JTAG, SPI, UART
GPIO 31
Supply Voltage - Operating 1.9 V to 3.6 V
Current - Receiving 12.4mA to 13.3mA
Current - Transmitting 6.8mA to 11.1mA
Temperature Range - Operating -40°C to 85°C
Dimension 48-VFQFN Exposed Pad
Win Source Part Number 004125-NRF24LE1-F16Q48-R
Popularity Medium
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NRF24LE1-F16Q48-R CAD Model

Description

The Nordic Semiconductor ASA 004125-NRF24LE1-F16Q48-R is a TxRx + MCU electronic component designed for use in RF/IF and RFID applications.

  • Frequency: 2.4GHz
  • Power Output: 0dBm
  • Sensitivity: -94dBm
  • Maximum Data Rate: 2Mbps
  • Memory Size: 16kB Flash and 1kB SRAM
  • Modulation: GFSK
  • Serial Interfaces: I2C, JTAG, SPI, and UART
  • Operating Temperature: -40°C to 85°C
  • Supply Voltage: 1.9 V to 3.6 V
  • Package: 48-VFQFN Exposed Pad
  • Popularity: medium popularity rating
