NXP 74HC4514N,652 4-to-16 Line Decoder/Demultiplexer

The NXP 74HC4514N,652 is a high-performance integrated circuit that serves as a 4-to-16 line decoder or demultiplexer. This versatile component is part of the 74HC (High-speed CMOS) family, offering the perfect blend of speed and power efficiency. The IC is designed for use in a wide range of digital applications, from general-purpose decoding tasks to more specific uses in system address decoding and data routing.

Key Features:

• Logic Family: The chip belongs to the 74HC family, which is known for its high-speed CMOS technology.
• Decoder Configuration: It features a 4-to-16 line decoder configuration, making it capable of decoding a 4-bit input to one of sixteen outputs.
• Supply Voltage Range: The 74HC4514N,652 operates within a supply voltage range of 2.0V to 6.0V, making it suitable for various logic level requirements.
• Output Capability: The IC comes with standard outputs that are capable of driving 15 LSTTL loads, ensuring compatibility with a wide range of digital systems.
• Latch Storage: It includes a latch storage function, which allows the input to be stored and maintained at the output until it is changed, adding to the device's flexibility.
• Input Levels: The device supports both TTL and CMOS input levels, providing design versatility.
• Package Type: The 74HC4514N,652 comes in a DIP-24 (Dual In-line Package) form factor, which is widely used and easy to handle for prototyping and production.

Applications:

The NXP 74HC4514N,652 can be used in a variety of digital systems, including:

• Memory chip selection
• Data multiplexing
• Address decoding for microprocessors
• Control systems
• Computer systems
• Embedded systems

With its robust design and the ability to interface with other logic families, the NXP 74HC4514N,652 is a reliable choice for designers looking to implement decoding or demultiplexing functionality in their digital logic designs.
