The NXP 74HCT597D is a high-performance, 8-bit shift register that combines an 8-bit storage latch and an 8-bit shift register with common serial input (DS) and output (Q7') lines. This integrated circuit is part of the 74HCT family, which is known for its high-speed Si-gate CMOS technology and compatibility with TTL (Transistor-Transistor Logic).

Key Features

• Logic Family: 74HCT
• Logic Type: 8-bit Shift Register with 8-bit Storage Latch
• Operating Voltage: 4.5V to 5.5V
• Output Capability: Standard
• Package: SO16 (Small Outline)
• Temperature Range: -40°C to +125°C

The device operates with a clock input (CP) that drives both the shift register and storage latch. It also has a shift register clear (MR) input to reset the internal shift register. The 74HCT597D is designed to interface directly with microprocessors and can be used in a wide range of applications, including data storage, data transferring, and digital signal processing.

Applications

• Data Storage Systems
• Serial-to-Parallel Data Conversion
• Digital Signal Processing
• Instrumentation and Control Systems

The 74HCT597D is recognized for its robustness and reliability, featuring a latch-up performance that exceeds 100 mA per JESD 78 Class II Level B. It also has an ESD protection exceeding JESD 22, ensuring the device's resilience against electrostatic discharge during handling and operation.

Designed for easy implementation and versatility, the NXP 74HCT597D is a practical choice for designers looking for a dependable shift register solution. Its performance, coupled with the quality assurance of NXP Semiconductors, makes it a valuable component in any digital logic application requiring serial-to-parallel data conversion or temporary data storage.
