The NXP 74LVC08APW is a high-performance, low-voltage CMOS device that belongs to the 74LVC family. This integrated circuit is designed to operate as a quad 2-input AND gate, which is fundamental in digital electronics for logical operations. The 74LVC08APW is suitable for use in a wide range of applications, from industrial and commercial to consumer electronics, where a reliable and efficient logical operation is required.

Key Features

• Logic Type: Quad 2-input AND gate
• Supply Voltage Range: 1.2V to 3.6V, making it ideal for low-voltage operations and compatible with TTL levels.
• High-Speed Performance: The device can switch at frequencies up to 50 MHz (typical) at a 3.3V supply, ensuring fast response times in critical applications.
• Low Power Consumption: With a low power dissipation and an ICC of 1 µA (max) at 25°C, it is excellent for battery-operated and power-sensitive devices.
• 5V Tolerant Inputs: Inputs can tolerate a voltage up to 5V, making the device compatible with mixed-voltage environments.
• Output Capability: Standard outputs with a 4 mA output drive at 3.3V, supporting moderate load conditions.
• Package: The device comes in a TSSOP14 (thin shrink small outline package) with a body width of 4.4 mm, which is suitable for space-constrained applications.
• Operating Temperature: Can operate in a broad temperature range from -40°C to +125°C, providing reliability across various environmental conditions.
• ESD Protection: High Electrostatic Discharge (ESD) protection levels with HBM JESD22-A114F exceeds 2000V and MM JESD22-A115-A exceeds 200V.

Applications

The 74LVC08APW is versatile and can be used in a variety of digital applications, including:

• Logic level shifting and translation
• Signal gating
• Function generators
• Embedded systems
• Microprocessor/microcontroller interfacing

With its robust design and comprehensive features, the NXP 74LVC08APW is a reliable choice for designers looking for a quad 2-input AND gate solution that delivers performance and efficiency.
