Product Overview: 74LVC1G04GW,125

The 74LVC1G04GW,125 is a high-performance, single inverter gate designed and manufactured by NXP Semiconductors, a leader in the industry. This product is part of the 74LVC series, which is renowned for its low-voltage CMOS technology. It offers a robust solution for various digital logic operations, making it a vital component in a wide range of electronic applications.

Key Features

• Logic Type: Single Inverter
• Package: TSSOP5 (SOT353)
• Operating Voltage: 1.65V to 5.5V
• Output Current: -32mA / 32mA
• Propagation Delay Time: 3.7ns at 3.3V
• Temperature Range: -40°C to +125°C
• ESD Protection: Exceeds 2000V HBM per JESD22-A114, 200V MM per JESD22-A115, and 1000V CDM per JESD22-C101

Performance and Quality

The 74LVC1G04GW,125 is designed to deliver high-speed performance with a low-power consumption profile, making it suitable for battery-operated devices. Its wide operating voltage range allows for compatibility with various logic levels, ensuring versatility in system design. The device also features a balanced propagation delay, which ensures fast response times in critical applications.

With its robust ESD protection, the 74LVC1G04GW,125 ensures reliability and longevity, even in harsh electrical environments. This level of protection is critical for maintaining the integrity of the device and the overall system in which it is used.

Applications

Due to its compact size and high functionality, the 74LVC1G04GW,125 is ideal for a multitude of applications, including:

• Mobile phones
• Computers and computer peripherals
• Portable gaming devices
• Medical equipment
• Networking and telecommunications
• Consumer electronics

Environmental Compliance

The 74LVC1G04GW,125 is compliant with the RoHS (Restriction of Hazardous Substances) directive, which means it is manufactured with a commitment to environmental safety. By avoiding hazardous materials in its construction, this product meets global standards for environmental responsibility and user safety.

With its combination of high-speed logic, low power consumption, and environmental compliance, the 74LVC1G04GW,125 from NXP is an excellent choice for designers seeking to create efficient, reliable, and eco-friendly electronic systems.
