Products specifications

Manufacturer NXP
Win Source Part Number 1185942-IP4791CZ12
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IP4791CZ12 CAD Model

Description

The IP4791CZ12 is a highly integrated device designed by NXP Semiconductors, tailored to enhance and protect High-Definition Multimedia Interface (HDMI) interfaces. This advanced component is engineered to provide a robust solution for applications that require high-speed data transmission and reception while maintaining signal integrity and protecting against electrostatic discharge (ESD).

Key Features

  • HDMI 1.4 Compliance: The IP4791CZ12 meets the specifications of HDMI version 1.4, ensuring compatibility with a wide range of multimedia devices.
  • Integrated ESD Protection: With built-in ESD protection, the device can withstand ESD pulses, minimizing the risk of damage to sensitive circuitry.
  • Low Capacitance: The low capacitance design ensures that high-speed signals are not significantly distorted, preserving signal quality over HDMI connections.
  • Active Pull-ups on TMDS Lines: This feature helps to maintain signal integrity, particularly over longer cable runs, by preventing signal attenuation.
  • Backdrive Protection: Protection against backdrive currents safeguards the device and the system during hot-plug events or when cables are disconnected.

Applications

The IP4791CZ12 is ideal for a range of applications that require reliable high-speed digital video and audio transmission. These include:

  • High-definition televisions (HDTVs)
  • Digital set-top boxes
  • Blu-ray players
  • Personal computers
  • Video game consoles

Technical Specifications

The device comes in a small TSSOP12 package, which is not only space-saving but also offers excellent thermal performance. It operates over a wide temperature range, making it suitable for various environments. The IP4791CZ12 also includes on-chip termination resistors for the differential lines, further reducing the need for external components and simplifying the design process for engineers.

With its comprehensive feature set, the IP4791CZ12 from NXP is a top choice for designers looking to enhance the performance and durability of their HDMI interfaces. Its integration of critical functions and protective measures ensures that it stands out in the market as a reliable and efficient solution for advanced multimedia applications.
