The NXP LD6805K/22H is a high-performance, low drop voltage regulator designed to deliver a stable and reliable power supply in a variety of electronic applications. This compact and efficient component is an ideal solution for space-constrained systems requiring a fixed output voltage with low power consumption and minimal voltage drop.

Key Features

• Output Voltage: The LD6805K/22H provides a fixed output voltage of 2.2V, which is ideal for powering low-voltage digital and analog circuits.
• Low Dropout: With its low dropout performance, it ensures efficient operation even when the input voltage is very close to the output voltage, reducing power loss and improving overall system efficiency.
• High Accuracy: The output voltage is maintained with high accuracy, providing a stable power supply that enhances the performance of sensitive electronic components.
• Current Capability: It is capable of supplying up to 150 mA of continuous load current, making it suitable for a broad range of applications.
• Thermal Protection: The device includes an integrated thermal protection feature that safeguards it against overheating, ensuring long-term reliability.
• Small Footprint: The LD6805K/22H comes in a small SOT-23 package, which is perfect for applications where board space is at a premium.

Applications

The NXP LD6805K/22H is versatile and can be used in various applications including but not limited to:

• Mobile Phones
• Portable Media Players
• Wireless Modules
• Microcontroller Power Supply
• Peripheral Power Supply

Quality and Reliability

NXP Semiconductors is known for its commitment to quality and reliability, and the LD6805K/22H is no exception. It is manufactured to meet the highest industry standards, ensuring that it performs consistently in the most demanding environments. Whether you are designing consumer electronics or industrial systems, the LD6805K/22H from NXP is a reliable choice for your voltage regulation needs.
