The LPC2294HBD144/01 is a high-performance microcontroller designed by NXP Semiconductors. It is part of the LPC2200 series based on a 16/32-bit ARM7TDMI-S CPU with real-time emulation that operates at up to 60 MHz. This microcontroller is ideal for applications requiring a high level of integration and low power consumption.

Key Features:

• Core: ARM7TDMI-S operating at up to 60 MHz.
• Memory: 256 KB of on-chip high-speed flash memory with 128-bit wide interface and 16 KB of static RAM.
• Digital Peripherals: Includes multiple 32-bit timers, an enhanced CAN controller, PWM channels, and up to 47 GPIO pins.
• Serial Interfaces: Features multiple serial interfaces such as UARTs, I2C-bus, SPI, and SSP with buffering and variable data length capabilities.
• System Control: Power control modes include Idle and Power-down modes for energy efficiency.
• Package: Comes in a compact 144-pin LQFP (Low-profile Quad Flat Package).

Applications:

The LPC2294HBD144/01 is versatile and can be used in a variety of applications. It is particularly well-suited for:

• Industrial control systems
• Medical systems
• Communication gateways
• Embedded soft modems
• Protocol converters
• Automotive body systems

Technical Specifications:

Parameter Value CPU Speed Up to 60 MHz Flash Memory 256 KB RAM 16 KB Package 144-LQFP Temperature Range -40°C to +85°C

For further information, datasheets, and support, visit the NXP Semiconductors official website.
