Products specifications

Categories Integrated Circuits (ICs)
Manufacturer NXP
Packaging Reel package
Applications Switch Monitoring
Interface SPI Serial
Operating Supply Voltage 3.1 V ~ 5.25 V
Package 32-SSOP (0.295", 7.50mm Width) Exposed Pad
Manufacturer Package 32-SOIC EP
Mounting SMD
Win Source Part Number 787762-MC33972ATEKR2
Popularity Medium
Supply and Demand Status Limited
Family Name MC33972
Introduction Date April 12, 2011
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MC33972ATEKR2 CAD Model

Description

The MC33972ATEKR2 is a sophisticated switch detection interface designed by NXP Semiconductors, renowned for its high-performance automotive solutions. This device is specifically engineered to monitor switch status in automotive applications, providing a reliable and efficient means of detecting open and closed conditions in a variety of switch types.

Key Features

  • Multiple Switch Inputs: The MC33972ATEKR2 can handle up to 22 switch inputs, making it a versatile solution for complex automotive systems that require monitoring of numerous switches simultaneously.
  • Wet and Dry Contact Modes: It supports both wetting current for oxidized contacts and dry switching, ensuring accurate detection across different environmental conditions and switch types.
  • Integrated Serial Peripheral Interface (SPI): The device offers a robust SPI for communication with microcontrollers, facilitating easy integration into automotive control systems.
  • Enhanced Diagnostics: It provides advanced diagnostic features for open and short circuit detection, helping to ensure system reliability and safety.
  • Voltage Range: The MC33972ATEKR2 operates over a broad range of supply voltages, accommodating the diverse electrical environments found in automotive applications.
  • Temperature Range: It is designed to withstand the extreme temperatures typically encountered in automotive environments, ensuring consistent performance.

Applications

The MC33972ATEKR2 is ideal for a variety of automotive applications, including but not limited to:

  • Body Control Modules
  • Steering Column Modules
  • Instrument Panel Clusters
  • Lighting Control Systems

Product Details

This device comes in a small outline integrated circuit package, which is suitable for space-constrained applications. Its robust design adheres to stringent automotive industry standards, making the MC33972ATEKR2 a reliable choice for automotive engineers seeking a switch detection interface that can cope with the rigors of vehicular use.

With its comprehensive feature set and strong diagnostic capabilities, the MC33972ATEKR2 from NXP Semiconductors stands out as a top-tier solution for automotive switch detection challenges.
