Products specifications Report Issue?

Manufacturer NXP USA Inc.
Applications Board Mount
Pressure Type Differential
Operating Pressure 7.25PSI (50kPa)
Output Type Wheatstone Bridge
Output 0 mV ~ 40 mV (10V)
Supply Voltage (V) 10V ~ 16V
Port Style No Port
Features Temperature Compensated
Termination Style PC Pin
Maximum Pressure 29.01PSI (200kPa)
Temperature Range - Operating -40°C ~ 125°C
Manufacturer Package 4-SIP Module
Manufacturer Pack Quantity 125
MSL Level Not Applicable
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 814217-MPX2050D
Ultra Librarian 3D Model Ultra Librarian MPX2050D CAD Model

Description

Introducing the MPX2050D Pressure Sensor from NXP

The MPX2050D is a highly reliable and accurate pressure sensor from the renowned semiconductor manufacturer, NXP Semiconductors. This device is designed to cater to a wide range of applications requiring precise pressure measurement, such as medical systems, industrial controls, and automotive sensors. The MPX2050D is part of NXP's MPX series, which is well-regarded for its performance and durability in challenging environments.

Key Features of the MPX2050D Pressure Sensor:

  • Pressure Range: The sensor can measure differential pressures ranging from 0 to 50 kPa (0 to 7.25 psi), making it versatile for various applications.
  • Sensitivity: It offers a high sensitivity of 90 mV/kPa, ensuring that even the smallest pressure changes are accurately detected and measured.
  • Dual Port Design: The MPX2050D comes with a dual port configuration, which allows for the measurement of pressure differences between two points, essential for various differential pressure measurement tasks.
  • Temperature Compensation: The sensor includes built-in temperature compensation from 0°C to +85°C, guaranteeing consistent performance across a broad temperature range.
  • Calibration: Each MPX2050D sensor is calibrated and temperature compensated for sensor offset, sensitivity, temperature effects, and accuracy errors, which ensures reliable and high-accuracy readings.
  • Construction: The sensor's small and lightweight design, with a high-quality silicon piezoresistive sensing element, offers excellent media compatibility and is suitable for use with non-corrosive, non-ionic working fluids such as air and dry gases.

Applications for the MPX2050D:

The MPX2050D's robustness and precision make it ideal for a variety of applications, including:

  • Medical devices such as respiratory equipment and blood pressure monitors
  • Industrial process control and automation
  • Pneumatic control systems
  • Airflow monitors
  • Level indicators for liquids and solids

The MPX2050D from NXP Semiconductors is a testament to NXP's commitment to providing high-quality sensors that meet the needs of today's sophisticated measurement and control systems. With its combination of accuracy, reliability, and versatility, the MPX2050D is an excellent choice for professionals seeking a top-tier pressure sensing solution.
