Product Overview: PSMN1R8-40YLC from NXP

The PSMN1R8-40YLC is a high-performance, N-channel enhancement mode Field Effect Transistor (FET) designed by NXP Semiconductors. This power MOSFET is a part of NXP's NextPowerS3 portfolio, which is renowned for its exceptional efficiency and thermal performance. It is ideal for a wide range of applications including power supplies, motor control, computing, and automotive systems.

Key Features

• Low On-State Resistance: With a typical RDS(on) of only 1.8 mΩ, this MOSFET ensures high efficiency and low conduction losses, making it suitable for high current applications.
• 40V Drain-Source Voltage: The device can handle a maximum drain-source voltage (VDS) of 40V, providing a good safety margin for most low to medium voltage applications.
• High Continuous Drain Current: It offers a high continuous drain current (ID) of up to 100A at 25°C, which is ideal for applications requiring high power density.
• Low Qg and Fast Switching: The MOSFET features low gate charge (Qg), which results in fast switching performance, reducing switching losses and improving overall efficiency.
• Enhanced Thermal Performance: The PSMN1R8-40YLC is housed in an LFPAK56 (Power-SO8) package, which is optimized for excellent thermal performance and reduced footprint on PCBs.

Applications

• DC/DC Converters
• Synchronous Rectification
• Power Management
• Motor Drives
• Automotive Systems

Quality and Reliability

NXP's commitment to quality and reliability is evident in the PSMN1R8-40YLC. The device is engineered to meet rigorous industry standards, ensuring stable performance across various environmental conditions. With features like its robust package design and advanced silicon technology, the PSMN1R8-40YLC is a dependable choice for designers looking to enhance system efficiency and longevity.

For detailed specifications and application support, visit NXP's official website or contact their customer service for further assistance.
