The TDA7052AT/N2,118 is an integrated circuit developed by NXP Semiconductors, designed to function as a mono bridge-tied load (BTL) output amplifier with DC volume control. This high-quality audio amplifier is an ideal solution for portable devices and applications where space is at a premium and minimal external components are desired.

Key Features

• Power Amplifier Type: The TDA7052AT/N2,118 is a 1-channel audio amplifier that can deliver a power output of 1.0 W, making it suitable for small to medium-sized audio applications.
• Supply Voltage: It operates efficiently over a wide supply voltage range of 4.5V to 18V, providing flexibility in various power environments.
• Volume Control: The amplifier features an integrated DC volume control that allows the user to adjust the output level, providing a convenient way to manage audio output without the need for additional components.
• Low Quiescent Current: With its low quiescent current draw, the TDA7052AT/N2,118 is optimized for battery-operated devices, ensuring minimal power consumption when in standby mode.
• No External Components: One of the standout features of this IC is that it requires no external components, which simplifies the design and reduces the overall cost of the end product.
• Thermal Protection: The device includes built-in thermal protection, safeguarding it against potential overheating and enhancing its reliability and lifespan.

Applications

The TDA7052AT/N2,118 is versatile and can be used in a variety of audio applications. It is particularly well-suited for:

• Portable audio devices such as radios, CD players, and MP3 players
• Miniature audio systems where space is limited
• Battery-powered audio applications
• Small amplifiers for computer or gaming accessories

Product Specifications

In summary, the TDA7052AT/N2,118 is a highly efficient, reliable, and user-friendly audio amplifier IC that offers excellent performance for a wide range of audio applications.
