NXP TJF1052I/5 High-Speed CAN Transceiver

The TJF1052I/5 is a high-performance, standalone High-Speed Controller Area Network (CAN) transceiver from NXP Semiconductors. It provides an interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. This transceiver is designed to meet the ISO11898-2:2016 standard and offers a feature-rich solution for automotive and industrial applications requiring robust communication with high electromagnetic compatibility (EMC).

Key Features

• ISO11898-2:2016 Compliant: Ensures reliable communication at data rates up to 1 Mbps.
• Low Power Mode: Features a low-power standby mode with remote wake-up capability, making it suitable for energy-sensitive applications.
• Bus Fault Protection: Equipped with extensive bus fault protection of ±58V against transients in automotive environments.
• Failure Management: The TJF1052I/5 includes an undervoltage detection feature and thermal protection to safeguard the transceiver from damage.
• Differential Receiver with Wide Common-Mode Range: Allows for reliable data reception in the presence of common-mode voltage variations, which is essential for robust bus communication.

Applications

With its robust design and advanced features, the TJF1052I/5 is ideal for a wide range of applications, including:

• Automotive networks
• Industrial control systems
• Heavy machinery
• Marine electronics
• Medical equipment

Product Summary

The NXP TJF1052I/5 transceiver is designed to provide reliable CAN communication in harsh environments. Its protective features and low power consumption make it an excellent choice for applications that demand high reliability and efficiency. Whether used in vehicles, industrial settings, or other sophisticated electronic systems, the TJF1052I/5 offers a dependable solution for CAN network interfacing.
