The EE-SA105 is a slot-type photointerrupter manufactured by Omron. This optical sensor is designed to detect the presence or absence of an object passing through the slot. It features a transistor output and is commonly used in various applications requiring non-contact object detection.

Applications:

• Printers and Copiers: Paper detection and position control.
• Vending Machines: Object detection and counting.
• Robotics: Position sensing and limit switches.
• Gaming Machines: Detecting coin insertion or lever position.
• Automated Equipment: Object counting and position control in production lines.

Features:

• Slot-Type Design: Allows for easy insertion of objects to be detected.
• Transistor Output: Provides a digital output signal indicating object presence.
• Non-Contact Detection: Detects objects without physical contact.
• Compact Size: Small form factor for space-constrained applications.
• High Sensitivity: Capable of detecting small objects.

Benefits:

• Reliable Detection: Ensures consistent and dependable object detection.
• Non-Contact Operation: Prevents wear and tear on the object being detected.
• Easy Integration: Simple to integrate into existing systems.
• Compact Design: Allows for use in tight spaces.
• Cost-Effective: Offers a balance of performance and cost.

Additional Details:

The EE-SA105 photointerrupter consists of an LED emitter and a phototransistor receiver. When an object blocks the light path between the emitter and receiver, the transistor output changes state. The operating voltage and current requirements are detailed in the manufacturer's datasheet. Proper alignment and shielding are essential to ensure optimal performance and prevent false triggering. The EE-SA105 meets industry standards for safety and performance.
